Supply table
Unit
Recommended Quan-
tity
Operating material Specifications
Engine 7.5L Engine oil API CJ-4 SAE15W-40
Hydraulic transmission
gear
9L Transmission oil Dexron Ⅲ/ Mobile ATF
Hydraulic system
38L for mast below
4500mm mast
Hydraulic oil
≥-5℃:L-HM46
≥-20℃:L-HV32(For cold
storage use)
40L for mast exceed-
ing 4500mm mast
Braking system 0.3L Brake fluid DOT-3
Bearings, lubricating
grease fittings
0.05KG Lubricating grease NLGL 2 lithium grease
Drive axle 6L Gear oil
-15℃~+49℃: GL-5
85W/90
-25℃~+49℃: GL-5
80W/90
(For cold storage use)
Cooling system
Radiator water tank:
11L
Coolant/water
See section "Engine cool-
ant-Specifications"
Reservoir box: 0.9L Coolant/water
Fuel
2.0-2.5T:20L
3.5T:23L
Diesel
See section "Diesel fuel-
Specifications"
WARNING
Use of products with specifications lower than those
set out in the table could cause damage to the truck
not covered by the warranty.
Maintenance
5
Scheduled truck maintenance
11360068011601 EN - 09/2020
