VDI Datasheet for RCD30
Characteristics
Manufacturer STILL
Model RCD30
Power type：Electric-Diesel-Petrol-LPG-Network Pow-
er (Electric)
Diesel
Operation Type:Hand-stand on-Driver seated Seated
Load Capacity Q (kg) 3000
Load centre of gravity distance c (mm) 500
Axle centre to fork face x (mm) 484
Wheel Base y (mm) 1700
Weights
Service Weight Kg 4500
Axle loading, laden front/rear Kg 6580/920
Axle loading, unladen front/rear Kg 1800/2700
Wheels, chassis frame
Tyres:SE-Super elastic PN-Pneumatic PN
Front Tyres Size 28X9–15/14PR
Rear Tyres Size 6.50-10/10PR
Front Track Width b10 (mm) 1000
Rear Track Width b11 (mm) 970
Dimension and overall sizes
Mast lift, forward/backward α/β 6°/12°
Mast Minimum Overall Height h1 (mm) 2080
Free lift h2 (mm) 145
Lift height h3 (mm) 3000
Mast Maximum Overall Height h4 (mm) 4273
Overhead Guard Height h6 (mm) 2110
Seat Height h7 (mm) 1165
Drawbar Height h10 (mm) 300
Overall Length I1 (mm) 3780
Length to Face of Forks I2 (mm) 2710
Overall Width b1 (mm) 1225
Fork Arm Dimensions s/e/l (mm) 45/125/1070
Fork Carriage in Compliance with ISO 2328 Class/Form
A,B
A
Fork Carriage Width b3 (mm) 1100
Ground Clearance below Mast(laden) m1 (mm) 135
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 140
Working aisle width with pallet 1000 x 1200 cross-
ways****
Ast (mm) 4144
Technical datasheet
6
VDI Datasheet for RCD30
14560068011601 EN - 09/2020
