Fork Carriage Width b3 (mm) 1040
Ground Clearance below Mast(laden) m1 (mm) 135
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 140
Working aisle width with pallet 1000 x 1200 cross-
ways****
Ast mm) 4119
Working aisle width with pallet 800 x 1200 cross-
ways****
Ast mm) 4319
Turning Radius Wa (mm) 2440
Turning Point Minimum Distance from the Truck Cen-
ter Line
b13 (mm) 810
Performance data
Driving speed (with/without load) km/h 18/18
Lifting speed (with/without load) m/s 0.57/0.59
Lowering speed (with/without load) m/s 0.48/0.40
Drawbar Pull Tractive Effort (at 2km/h) with/without
load
KN 19/16
Gradeability (at 2km/h) laden/unladen % 20/20
Service Brake Mechanical/Hydraulic
Engine
Engine Type DOOSAN D24
Engine Power in compliance with ISO 1585 kW 36.4
Rated Number of Revolutions rpm/min 2400
Cylinder Number/Displacement cm
3
4/2400
On-board voltage V 12
Others
Drive Control Type
Hydraulic torque con-
verter
Volume fuel tank L 62
Towing coupling, type DIN 15170 PIN
Technical datasheet
6
VDI Datasheet for RCD25
144 60068011601 EN - 09/2020
