Still RCD25 User Manual

VDI Datasheet for RCD25
NOTE
This VDI data sheet specifies only the techni-
cal values of the truck version with standard
equipment. Different tyres, lift masts, addition-
al units etc. may produce different values.
Characteristics
Manufacturer STILL
Model RCD25
Power type：Electric-Diesel-Petrol-LPG-Network
Power (Electric)
Diesel
Operation Type:Hand-stand on-Driver seated Seated
Load Capacity Q (kg) 2500
Load centre of gravity distance c (mm) 500
Axle centre to fork face x (mm) 479
Wheel Base y (mm) 1700
Weights
Service Weight Kg 4050
Axle loading, laden front/rear Kg 5820/730
Axle loading, unladen front/rear Kg 1530/2520
Wheels, chassis frame
Tyres:SE-Super elastic PN-Pneumatic SE
Front Tyres Size 28x9–15/14PR
Rear Tyres Size 6.50-10/10PR
Front Track Width b10 (mm) 1000
Rear Track Width b11 (mm) 970
Dimension and overall sizes
Mast lift, forward/backward α/β 6°/12°
Mast Minimum Overall Height h1 (mm) 2080
Free lift h2 [(mm) 140
Lift height h3 (mm) 3000
Mast Maximum Overall Height h4 (mm) 4040
Overhead Guard Height h6 (mm) 2110
Seat Height h7 (mm) 1165
Drawbar Height h10 (mm) 300
Overall Length I1 (mm) 3730
Length to Face of Forks I2 (mm) 2660
Overall Width b1 (mm) 1225
Fork Arm Dimensions s/e/l (mm) 40/122/1070
Fork Carriage in Compliance with ISO 2328 Class/
Form A,B
A
Technical datasheet
6
VDI Datasheet for RCD25
14360068011601 EN - 09/2020

Still RCD25 Specifications

General

Brand	Still
Model	RCD25
Category	Trucks
Language	English
