Still RCD25 User Manual

VDI Datasheet for RCD35
Characteristics
Manufacturer STILL
Model RCD35
Power type：Electric-Diesel-Petrol-LPG-Network Pow-
er (Electric)
Diesel
Operation Type:Hand-stand on-Driver seated Seated
Load Capacity Q (kg) 3500
Load centre of gravity distance c (mm) 500
Axle centre to fork face x (mm) 489
Wheel Base y (mm) 1700
Weights
Service Weight Kg 4980
Axle loading, laden front/rear Kg 7280/1200
Axle loading, unladen front/rear Kg 1680/3300
Wheels, chassis frame
Tyres:SE-Super elastic PN-Pneumatic PN
Front Tyres Size 28X9–15–14PR
Rear Tyres Size 6.50-10-10PR
Front Track Width b10 (mm) 1060
Rear Track Width b11 (mm) 970
Dimension and overall sizes
Mast lift, forward/backward α/β 6°/12°
Mast Minimum Overall Height h1 (mm) 2230
Free lift h2 (mm) 150
Lift height h3 (mm) 3000
Mast Maximum Overall Height h4 (mm) 4273
Overhead Guard Height h6 (mm) 2110
Seat Height h7 (mm) 1165
Drawbar Height h10 (mm) 300
Overall Length I1 (mm) 3880
Length to Face of Forks I2 (mm) 2810
Overall Width b1 (mm) 1285
Fork Arm Dimensions s/e/l (mm) 45/125/1070
Fork Carriage in Compliance with ISO 2328 Class/Form
A,B
A
Fork Carriage Width b3 (mm) 1100
Ground Clearance below Mast(laden) m1 (mm) 135
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 140
Working aisle width with pallet 1000 x 1200 cross-
ways****
Ast (mm) 4229
Technical datasheet
6
VDI Datasheet for RCD35
14760068011601 EN - 09/2020

Still RCD25 Specifications
