Sideways movement
NOTE
In order to prevent damage, do not operate in
a sideways direction when the fork arms are
on the ground.
– Push the control lever (3) forwards and
move to the left.
– Push the control lever (3) backwards and
move to the right.
Operating fixtures
– Push the control lever (4) forwards to open
the jig.
– Push the control lever (4) backwards to
clamp the jig.
Use and operation
4
Lifting system and attachments
72 60068011601 EN - 09/2020
