Objet350 User Guide 6 Operating and Maintaining the Objet350 3DPrinter
DOC-17001 Rev.G 6-73
6. LoosenthescrewsecuringtheUVlampcover(A),andpullthecoverup
(B),thenout(C).
Figure6-111RemovingtheUVlampcover
7. PulltheUVlampreflectoroutoftheprintblock.
Figure6-112RemovingtheUVlampreflector
8. InspectthenewUVlampreflector,andmakesurethatablackstripis
attachedtotheinsideofit.Ifnot,installone—onthesideofthereflector
opposite(notnextto)theprintblock.
Note: ExtrablackstripsareincludedintheprinterStart-UpKit.Ifnecessary,
youcanremovetheblackstripfromtheoldreflectorandinstallitinthenew
reflector(aslongastheblackpainthasnotfaded).
9. DiscardtheoldUVreflectorandlamp.
DisposeoftheusedUVlampinaccordancewithenvironmentaland
safetyrequirements.
