Objet350 User Guide 5 Using Objet Studio
DOC-17001 Rev.G 5-35
Manipulating Objects on the Tray
Positioning
Objects on the
Z-Axis
Whenyouusetheautomaticpositioningoptiontoarrangeobjectsonthe
buildtray(see"AutomaticOrientation"onpage5-30),theobjectsare
positioneddirectlyonthetray.Ifyoudonotinsertobjectswithautomatic
positioning,theyoftenappeareitheraboveorbelowthetray.
Inpractice,theObjetsystemprintsallmodelsonthebuildtrayonaone-
millimeterbedofsupportmaterial.Theimportanceofpositioningobjects
directlyonthebuildtraywithObjetStudioistocorrectlydisplaytheobjects
onthescreen.
Topositionobjectsdirectlyonthetray:
1. Selecttheobject.
2. FromtheObjectmenu,selectLayOn.
Toensurethatobjectsarealwayspositioneddirectlyonthetray:
1. FromtheToolsmenu,selectOptions,anddisplaytheSettingstab.
Figure5-38Optionsdialogbox,Settings tab
2. IntheAutomatic Lay On (Gravity)section,selectAlways.
OtherZ-axisoptions(intheAutomatic Lay On section):
•Whenunderthetray—Thedisplayofobjectsthatarebelowthebuildtrayis
automaticallychangedsothattheobjectisattraylevel.
•Never—Thedisplayofobjectsthatareaboveorbelowthebuildtrayisnot
changed.
