19
4Operation
Display panel and keypad
The main user interface for the printer is the display panel and keypad. See Figure 15.
Figure 15 Display panel and keypad
The uPrint and uPrint Plus display panel and keypad consist of a multiple-line LCD window with two
buttons used for scrolling through messages and four single-line windows, each with one button for
making selections. The top line in the upper window always shows the printer status.
1 Keypad buttons
2 Main display window
3Lower display windows
Note: If an item is blinking in the lower displays, the blinking item is usually
the next most logical selection.
