31
Figure 22 Rewinding the material spool
7. Using a cutters, cut the excess 2 inches (50mm) of material from the material guide, leaving a
blunt end.
8. Locate the two material retaining clips on the carrier. See Figure 23.
Figure 23 Material retaining clips
9. Place the material guide in the material guide slot on the spool. See Figure 24.
10. Place the material in the material notches. See Figure 24.
Figure 24 Material guide slot and detents
11. Cut the excess material from material guide.
12. Place the material retaining clips on the spool before removing the spool from the carrier. See
Figure 25.
a. Push the material retaining clips over the material and clip on to the
material spool.
b. Push the material retaining clips down until they lock in place.
