3. Place a spacing disc at a height of 20 mm
on the preparation surface so that it is
below the edge of the flexible specimen
holder.
A Spacing disc
4. Support the LaboForce-100 head and
loosen the screw in the adjustment ring.
A V-shaped groove
B Pin
C Adjustment ring
D Fastening screw
5. Press the Lower/Raise button to lower the
specimen mover head. An error message
will appear as the specimen mover head is
not in contact with the adjustment ring.
