Procedure
1. Remove the back plate.
2. Remove the tube from the pump unit:
The white connector must remain on the
tube connected to LaboForce-100.
3. Press the two tabs at the base of the
pump and remove the pump from the
axle.
A Tabs
4. Remove the three rollers.
5. Remove the Novoprene tube.
6. Make a note of the distance between the
two white clips on the Novoprene tube.
7. Move the white clips and the connector to
the new silicone tube.
8. Fit the new tube into the housing and
press it firmly into place.
9. Press the three rollers into the pump
housing.
10. Mount the tube correctly in the pump.
80 LaboPol-60
11 LaboDoser-100
