STYLE 350 - Default Chapter; Table of Contents

Machine manual STYLE 350 – 510 V4.9
2
1 PREFACE 4
1.1 USER MANUAL 4
1.2 DOCUMENTS APPLYING TO MACHINE 4
1.3 EC DECLARATION OF CONFORMITY OF THE MACHINERY 5
2 SAFETY 6
2.1 SAFETY GUIDELINES 7
2.2 SAFETY COMPONENTS 7
2.2.1 EMERGENCY BUTTON 7
2.2.2 MACHINE PROTECTION 7
2.2.3 ELECTRICAL CABINET 7
2.2.4 MOVEMENT CROSS SLIDE 7
2.2.5 LUBRICATION 7
3 MACHINE SPECIFICATIONS 8
3.1 TECHNICAL SPECIFICATIONS 8
3.2 MACHINE OVERVIEW 9
3.2.1 FRONT SIDE 9
3.2.2 BACKSIDE 11
3.2.3 CONSOLE 12
3.3 WORKING SPACE DIMENSIONS 13
3.4 TORQUE DIAGRAM 14
3.4.1 STYLE 350 - 5,5 KW 14
3.4.2 STYLE 350 - 7,5 KW 14
3.4.3 STYLE 510 - 7,5 KW 15
3.4.4 STYLE 510 - 11 KW 15
3.4.5 STYLE 510 - 11 KW - (Ø102 SPINDLE BORE) 16
3.5 NOISE LEVEL 16
3.6 MACHINE LIGHTS 16
3.7 SWITCHES AND ENCODERS 17
3.7.1 SWITCHES 17
3.7.2 ENCODERS 17
4 INSTALLATION OF THE MACHINE 18
4.1 ENVIRONMENT REQUIREMENTS 18
4.2 FOUNDATION 18
4.3 PREPARATION FOR POSITIONING THE MACHINE 18
4.3.1 FUSE SPECIFICATIONS ELECTRICAL SUPPLY 18
4.3.2 COMPRESSED AIR 18
4.4 MOVING THE MACHINE 19
4.5 LEVELLING THE MACHINE 19
4.6 CHECKS BEFORE COMMISSIONING THE MACHINE 19
4.7 MOUNTING CHUCK 20
