STYLE 350 - Machine Specifications; Technical specifications

Machine manual STYLE 350 – 510 V4.9
8
3 Machine specifications
3.1 Technical specifications
Machine type
STYLE 350
STYLE 510
Ø54 bore
Ø80 bore
Ø102 bore
Main spindle
Main motor
[kW]
5,5 / 7,5
7,5 / 11
11
Maximum torque main spindle
[Nm]
373 / 509
718 / 1.050
1.180
Max. RPM
[rpm]
3000 (4000)
2500
1800 (2100)
Number of gears
[-]
3
3
3
Spindle bore
[mm]
Ø54
Ø80
Ø102
Spindle nose (camlock)
Spindle nose (hydraulic chuck)
[-]
[-]
D1-6
A2-6
D1-8
A2-8
D1-8
A2-8
Dimension thread backside spindle
[mm]
Ø56 – 16TPI
M82x2
M104x2
(850 dbc)
(1350 dbc)
(1850 dbc)
Machine
Swing over bed
[mm]
380
510
Swing over support
[mm]
190
300
Center height from support
[mm]
± 112
± 152
Distance between centers (dbc)
Heavy tailstock option (dbc)
[mm]
[mm]
850
1350
1200
1850
1700
Bed width
[mm]
305
330
Max. weight between centers
[kg]
300
600
X-axis
Diameter ball screw X-axis
[mm]
Ø 25
Ø 25
Pitch ball screw X-axis
[mm]
5
5
Rapid feed X-axis
[m/min]
8
8
Feed rate
[mm/min]
0,01 - 1000
0,01 - 1000
Movement X-axis
[mm]
180
260
Z-axis
Diameter ball screw Z-axis
[mm]
Ø 40
Ø 40
Pitch ball screw Z-axis
[mm]
5
5
Rapid feed Z-axis
[m/min]
8
8
Feed rate
[mm/min]
0,01 - 1000
0,01 - 1000
Tailstock
Quill diameter
[mm]
54
75
Quill stroke
[mm]
100
160
Quill taper
[MK]
4
5
General
Weight
[kg]
2000
2700
3250
Volume coolant tank
[L]
90 L
90 L
