Machine manual STYLE 350 – 510 V4.9
32. Changing the spindle speed has to be done when the machine is stopped. Never change the machine to
another gear while it is running.
33. Never rotate the spindle by hand, except when the emergency stop button is pressed.
34. Never rotate the chuck with more RPM than indicated.
35. Follow all the warnings and instructions of the chuck manufacture and the clamping procedure.
36. Tighten the work piece sufficient between the claws of the chuck. Improper or insufficient clamped work
pieces can come through the safety doors with high speeds. The operator should use a safe, lower RPM
during machining bigger or hardly strained pieces. Machining work pieces that are too big or parts that
are nearly clamped is not safe. Stop and disconnect the machine from the main power source before
replacing the following parts: belts, pulley, gears, and other moving parts, parts within reach of moving
parts or electrical power.
37. It is not allowed to apply maintenance unless the electricity is unplugged
38. Replace damaged or seriously scratched windows and control panels immediately
Under no circumstance it is allowed to use the machine for other purpose that it is
designed for and is described in this and 'Style Lathe' and 'CNC-Edit' software
manuals. STYLE CNC Machines is not responsible in any way for accidents and
injuries caused by improper use of the machine and not following instructions stated
in the manuals.
2.1 Safety guidelines
The STYLE flatbed lathe is designed and built according to the appropriate European standards (see the EG
document in the appendix).
2.2 Safety components
2.2.1 Emergency button
The emergency button is integrated in the control panel, and also on top of the optional chip conveyor. When the
emergency button will be activated all (motorized) movements will be stopped and disconnected from the main
power.
Use the emergency stop button only in case of danger. Never use this button as a
power switch or soft-stop button.
2.2.2 Machine protection
To prevent entanglement by moving parts a door interlock is used. The door interlock is mounted on the left door
and it is controlled by the software. It is not possible to start the main spindle in automatic mode while the door is
opened.
Never operate the machine when the doors are open.
2.2.3 Electrical cabinet
When the main switch is switched to”0-OFF” the electrical power is removed from the machine.
When service operation has to be made to the electrical cabinet this switch has to be switched to “0-OFF” in order
to open the door to the cabinet. Also the electrical connection has to be removed.
2.2.4 Movement cross slide
The travel of the support is limited by the control software. Yet it is recommended to prevent damage to the
machine not to move the support into the limit switches.
2.2.5 Lubrication
In the automatic lubrication pump a level switch is mounted in the reservoir for measuring the oil level. When the
oil level is too low, a warning message is displayed on the console screen.
