5.13 Spindle leakage hub
The spindle leakage hub must be attached to the spindle at all times. When the spindle leakage hub is removed,
cooling will return to the gearbox and will permanently damage the gearbox.
5.14 Filtermist (optional)
A Filtermist unit is an oil mist collector that use centrifugal impaction to remove or reclaim oil mist, coolant,
fume and steam from the working area of the machine.
• Off - The Filtermist will be disabled, even if coolant is programmed in
the software.
• Automatic - The Filtermist will be enabled if this is programmed in the
software.
• On - When the machine is activated the Filtermist will be enabled
direct.
