FU(H4SO)-8
FUEL INJECTION (FUEL SYSTEMS)
General Description
3. CRANKSHAFT POSITION, CAMSHAFT POSITION AND KNOCK SENSORS
(1) Crankshaft position sensor (4) Camshaft position sensor support Tightening torque: N·m (kgf-m, ft-lb)
(2) Knock sensor T1: 6.4 (0.65, 4.7)
(3) Camshaft position sensor T2: 24 (2.4, 17.4)
FU-00414
T1
(1)
(2)
T1
T1
(3)
(4)
T2
