FU(H4SOw/oOBD)-38
FUEL INJECTION (FUEL SYSTEMS)
Fuel Injector
2. LH SIDE
1) Release the fuel pressure. <Ref. to FU(H4SOw/
oOBD)-46, RELEASING OF FUEL PRESSURE,
OPERATION, Fuel.>
2) Open the fuel filler flap lid and remove the fuel
filler cap.
3) Disconnect the ground cable from battery.
4) Remove the two bolts which install the washer
tank on body.
5) Disconnect the connector from front window
washer motor.
6) Disconnect the connector from rear gate glass
washer motor.
7) Disconnect the rear window glass washer hose
from washer motor, and then plug the connection
with a suitable cap.
8) Move the washer tank, and secure it away from
working area.
9) Remove the spark plug cords from spark plugs
(#2 and #4 cylinders).
10) Remove the fuel pipe protector LH.
11) Disconnect the connector from fuel injector.
FU-00009
FU-00190
FU-00191
FU-00192
FU-00307
FU-00266
FU-00941
To Next Page
