1-2 Sun Fire X2100 Server User Guide • April 2007
1.1 Features
TABLE 1-1 shows the system’s key components.
TABLE 1-1 Sun Fire X2100 Server Features
Component Description
CPU • One single- or dual-core AMD Operton processor
• Processor frequencies: 2.2 GHz and faster
• Up to 1 MB level 2 cache
Memory • Four DIMM slots
• Each DIMM socket supports 512 MB, 1 GB, and 2 GB DDR1 400
SDRAM (3.05 cm max. height) modules
• Unbuffered ECC memory
Media storage • Optional DVD-ROM
Hard disk drives • Up to two SATA disk drives
Power supply • 300W PSU
Network I/O • Two 10/100/1000BASE-T Gigabit Ethernet ports
PCI I/O • One PCI-Express x8 riser card supporting full-height, short length
x1, x4 or x8 cards up to 25W
Other I/O • Four USB 2.0 connectors on the rear panel and two on the front
panel
• Onboard ATI Rage XL PCI graphics controller with 8 MB memory
• One serial RS232 port with DB9 connector
System management • Optional IPMI 1.5 compliant service processor module
