4-18 Sun Fire X2100 Server User Guide • April 2007
2. Grasping the body of the drive in both hands, carefully guide the connector end
of the carrier into the drive bay, sliding the carrier into the bay until the arm
engages and partially closes itself.
3. Push the arm forward and latch it to lock the carrier in place.
4.5.5 SATA Backplane
The following procedure describes how to replace the SATA backplane.
4.5.5.1 Removing the SATA Backplane
Follow these steps to remove the SATA backplane:
1. Power off the system and remove the cover as described in Section 4.3, “Powering
Off the Server and Removing the Cover” on page 4-3.
2. Remove all hard disk drive (HDD) carriers:
a. Squeeze the release latch and swing the arm to the left as far as it will go.
b. Grasp the carrier bezel with both hands and carefully pull the carrier out of the
drive bay (see
FIGURE 4-12).
Note – Avoid using the arm to remove the carrier.
3. Disconnect the power, SATA, fan, and DVD and IDE cables from the SATA
backplane (see
FIGURE 4-38).
Caution – The small flat cables are extremely fragile. Use care when disconnecting
and connecting these cables.
