1.3 Hardware System Overview
The following sections describe the hardware orientation and features of your Sun
Fire X2100 Server.
1.3.1 Front and Rear Panels
FIGURE 1-1 illustrates the front panel of the Sun Fire X2100 Server.
FIGURE 1-1 Front Panel
TABLE 1-3 Front Panel
Label Button/LED/Port Label Button/LED/port
1 Locate LED 5 USB ports (2)
2 Status LED 6 DVD drive (optional)
3 Power LED 7 Hard disk drives (0, 1 or 2 optional)
4 Power button
HDD1 HDD1
21345 67
