TABLE 2-1 describes how to remove and install server filler panels.
TABLE 2-1 Server Filler Panel Removal and Replacement Procedures
Filler Panel Type Removal Procedure Install Procedure
Memory 1. Locate the memory module filler panel
to be removed from the motherboard.
2. Simultaneously press down on both
ejector levers at the ends of the memory
module slot.
3. Lift the filler panel straight up to remove
it from the memory module socket.
1. Locate the vacant memory module slot on the
motherboard.
2. Ensure that ejector levers at both ends of the
memory module slot are in a fully opened
position.
3. Align the memory module filler panel with
with the empty slot, then gently press the
filler panel into the slot until both ejector
levers close, locking the filler panel in place.
CPU
Note - CPUs
should only be
removed or
installed by Sun
qualified service
personnel.
1. To remove the CPU filler panel in the
socket, pull the release lever away from
the socket into a fully opened position.
2. Lift the bail and then gently lift the filler
panel straight up and out of the CPU
socket.
1. Ensure that the CPU socket release lever and
bail are in a fully opened position.
2. Gently insert the filler panel onto the exposed
pins in the CPU socket.
3. After the filler panel is fully seated in the
socket, close the bail onto the top of the filler
panel, then pivot the release lever down and
into the locked position at the side of the
socket.
Disk Drive 1. Locate the disk drive filler panel to be
removed from the server.
2. To unlatch the disk drive filler panel,
press the release lever button then tilt
the lever up into a fully opened position.
3. To remove the filler panel from the slot,
hold the opened release lever and gently
slide the filler panel toward you.
1. Locate the vacant disk drive module slot in
the server, then ensure that the release lever
on the filler panel is fully opened.
2. Slide the filler panel into the vacant slot by
pressing the middle of the filler panel
faceplate with your thumb or finger.
The release lever will lower as it makes
contact with the chassis. Do not slide the
filler panel in all the way. Leave the filler
panel out approximately 0.25 to 0.50 inch (6
to 12 mm) from the opening
3. Using your thumb or finger, press on the
middle of the filler panel faceplate until the
release lever engages with the chassis.
4. Close the release lever until it clicks into
place and is flush with the front of the server.
