Chapter 3 Installing the Server Into a Rack With Slide-Rails 61
8. If available, extend the anti-tip bar at the bottom of the rack (see FIGURE 3-5).
FIGURE 3-5 Extending the Anti-tip Bar
Caution – If your rack does not have an anti-tip bar, the rack could tip over.
▼ Attach Tool-less Slide-Rail Assemblies
To attach tool-less slide-rail assemblies to the rack, refer to the installation card
instructions included with the rackmount kit.
Installing the Server Into the Slide-Rail
Assemblies
Use this procedure to install the server chassis, with mounting brackets, into the
slide-rail assemblies that are mounted to the rack.
Caution – This procedure requires a minimum of two
people because of the weight of the server. Attempting this
procedure alone could result in equipment damage or
personal injury.
