Chapter 2 Installing Server Options 37
Installing a Hard Disk Drive
To install a hard disk drive, see the following procedure.
▼ Install the Hard Disk Drive
1. Attach an antistatic wrist strap.
See “ESD Handling Procedure” on page 22.
2. Prepare the server to install options.
See “Preparing the Server to Install Options” on page 22.
Note – You do not need to remove the server’s cover to install a hard drive.
3. Unpack the hard disk drive and place it on an antistatic mat.
4. Install the hardware.
a. Refer to
TABLE 2-5 and verify that your server will support the hard disk
drive you intend to install.
b. Determine the drive slot location for the hard disk drive.
Select the first available hard disk drive location starting with the lowest
numbered slot, HDD0. For example, if the server has two existing hard drives,
install the hard drive in slot HDD2.
c. Remove the hard disk drive filler panel from the server chassis for the
location into which you intend to install the hard drive.
See “Filler Panel Removal and Installation” on page 19.
d. Hard disk drives are physically addressed according to the slot in which
they are installed. See
FIGURE 2-6, FIGURE 2-7 and FIGURE 2-8 for hard drive
locations.
e. Slide the drive into the drive slot until it is fully seated (see
FIGURE 2-9).
