Chapter 2 Installing Server Options 35
FIGURE 2-7 X4270 Server Front Panel
FIGURE 2-8 shows the physical drive locations for the Sun Fire X4275 Server with 12
3.5-inch hard drives.
FIGURE 2-8 Sun Fire X4275 Server Front Panel
Figure Leg end
HDD3 HDD7 HDD12 HDD15
HDD2 HDD6 HDD11 HDD14
HDD1 HDD5 HDD9 DVD and USB Connectors (2)
HDD0 HDD4 HDD8 HDD10 HDD13
Figure Leg end
HDD2 HDD5 HDD8 HDD11
HDD1 HDD4 HDD7 HDD10
HDD0 HDD3 HDD6 HDD9
