Chapter 3 Installing the Server Into a Rack With Slide-Rails 53
Checking Rack Compatibility
Check that your rack is compatible with the slide-rail and cable management arm
(CMA) options. The optional slide-rails are compatible with a wide range of
equipment racks that meet the following standards.
Caution – Always load equipment into a rack from the bottom up so that it will not
become top-heavy and tip over. Deploy your rack’s anti-tip bar to prevent the rack
from tipping during equipment installation.
TABLE 3-1 Rack Compatibility
Item Requirement
Structure Four-post rack (mounting at both front and rear).
Two-post racks are not compatible.
Rack horizontal opening and unit
vertical pitch
Conforms to ANSI/EIA 310-D-1992 or IEC 60927
standards.
Distance between front and rear
mounting planes
Minimum 610 mm and maximum 915 mm
(24 inches to 36 inches).
Clearance depth in front of front
mounting plane
Distance to front cabinet door is at least 25.4 mm
(1 inch).
Clearance depth behind front
mounting plane
Distance to rear cabinet door is at least 800 mm (31.5
inches) with the cable management arm, or 700 mm
(27.5 inches) without the cable management arm.
Clearance width between front and
rear mounting planes
Distance between structural supports and cable
troughs is at least 456 mm (18 inches).
Server dimensions See
TABLE 3-1 for server dimensions.
