Sungrow SC1200UD-US User Manual

49
table 6-2 Cable Specification of Multi-branch Version
Cable
Specifications
Connec-
tion
holes
Requ.
Note
DC input
The cross-sectional area of
the positive and negative in-
put cables is 240 mm
2
(or 600
kcmil)at most
Each
branch
has two
wiring
holes.
Φ13
Alumi-
num/
Copper
cables
can be
flexibly
selected
to bear
the max
current.
AC output
The cross-sectional area of
each phase inputs is 240 mm
2
(or 600 kcmil)at most (PCS
stand-alone AC output side)
Six inputs,
each with
two holes
arranged
up and
down for
each
phase
wiring.
Φ13
Alumi-
num/
Copper
cables
can be
flexibly
selected
to bear
the max
current.
RS485 communica-
tion cable
2-core twisted shielded pair
cable
- - -
Can communication
cable
0.75 mm
2
- - -
Network cable Standard network cable
- - -
Cable overload is strictly prohibited!
• The recommended specifications above only apply to copper cables. If alumi-
num cables are used on site, please choose cables with appropriate cross-
sectional areas.
• Cable specifications and input numbers above are for a standard PCS. Should
you have any specific requirements, please inform us. Please refer to the ac-
tual product you received for the detailed specification.
User Manual 6 Electrical Connection
