Sungrow SH5K - Grid Standards and Parameter Configuration

User Manual 7 Commissioning
53
Tab. 7-2 Grid Standard Description
Grid company Code Company
AG AusGrid, NSW
EE Ergon Energy, QLD
EG Energex, QLD
PN SA Power Networks,SA
PC Powercor,VIC
WP Western Power,WA
Default Company not mentioned above
Tab. 7-3 Parameters of Grid Standards
Parameter Default AG EE EG PN PC WP
Over-voltage
1-V
max
(V) 260.0 260.0 260.0 260.0 257.0 260.0 260.0
1-Time (s) 2.0 1.80 1.80 1.80 1.80 1.80 1.80
2-V
max
(V) 265.0 265.0 265.0 265.0 265.0 265.0 265.0
2-Time (s) 0.20 0.20 0.20 0.20 0.20 0.20 0.20
Under-voltage
1-V
min
(V) 180.0 200.0 210.0 210.0 200.0 195.0 180.0
1-Time (s) 2.0 1.80 1.80 1.80 1.80 1.80 1.80
2-V
min
(V) 180.0 200.0 210.0 210.0 200.0 195.0 180.0
2-Time (s) 2.0 1.80 1.80 1.80 1.80 1.80 1.80
Over-frequency
1-F
max
(Hz) 52.00 52.00 52.00 52.00 52.00 51.50 51.50
1-Time (s) 0.20 0.20 0.20 0.20 0.20 0.20 0.20
2-F
max
(Hz) 52.00 52.00 52.00 52.00 52.00 51.50 51.50
2-Time (s) 0.20 0.20 0.20 0.20 0.20 0.20 0.20
Under-frequency
1-F
min
(Hz) 47.00 48.00 47.00 47.00 48.00 48.50 47.00
1-Time (s) 2.0 1.80 1.80 1.80 1.80 1.80 1.80
2-F
min
(Hz) 47.00 48.00 47.00 47.00 48.00 48.50 47.00
2-Time (s) 2.0 1.80 1.80 1.80 1.80 1.80 1.80
10-min voltage
1-V
10-min
(V) 255.0 255.0 255.0 257.0 255.0 255.0 258.0
1-V
10-min
(V) 255.0 255.0 255.0 257.0 255.0 255.0 258.0
* Refer to Tab. 10-3 for the parameter explanations.
y
Set the Grid standard for the country code “AU”. Set the protective parameters if
you choose “Manual”.
