57
No. Function StepRange
Initial value
26 Selection of B/T Solenoid operation position 0 0/1 0= lower position
1= upper position
27 Setting the maximum sewing speed of the machine according to ? ? program P1xx → P2xx → P3xx
presser foot-lift height of the KM-1060BL sewing machine. in order
Less than P1xx:3500[spm]
Less than P2xx:3000[spm]
Less than P3xx:2500[spm]
More than P3xx: A20[spm]
28 Needle bar’s automatic stop at the highest position 0 0/1
29 Pedal analog filtering difference 15 1~200 1
30 When using an angle 2-needle, select the semi-automatic corner operation 0 0/1 1=selection of semi-automatic
31 Speed when selecting a semi-automatic corner 200spm 20~2000 10spm
(parameter used only when used after selecting number 30)
32 After selecting the left needle the first sewing stitch 3 stitches 0~255 1 stitch
(parameter used only when used after selecting number 30)
33 After selecting the left needle the second sewing stitch 3 stitches 0~255 1 stitch
(parameter used only when used after selecting number 30)
34 After selecting the right needle the first sewing stitch 3 stitches 0~255 1 stitch
(parameter used only when used after selecting number 30)
35 After selecting the right needle the second sewing stitch 3 stitches 0~255 1 stitch
(parameter used only when used after selecting number 30)
36 Maintaining time for the left/right needle solenoid 450×0.1sec 50~1000 0.5sec
(After the programmed time the solenoid is automatically released)
37 NOT USED
38 NOT USED
39 Stopping function during AUTO mode and while pedal is neutral 1 0/1 0=does not stop
1=stops
40 Selection of type of N-stitch Sensor 0 0：active high 1：active low
41 The number of stitches done after the N-stitch Sensor has finished sensing. 3 stitches 0~255 1 stitch
(After sensing, it will sew the programmed number of stitches and stop)
42 N-stitch sewing speed 1000spm 20~2000 10spm
43 Selection of One Touch function → replaced by AUTO Key function 0 0/1 1=Auto Mode
(Used in the sewing mode that uses the auto function)
44 Selection of One Touch function → replaced by AUTO sewing mode programming 0 0/1 1=One-Shot Mode
(If there is no thread trimming signal when selected, sewing will continue even if user releases pedal)
45
One-Shot sewing speed → When using AUTO function, it is programmed with the speed Up/Dn Key
2000spm 40~9960 40spm
46 N-stitch sewing mode selection → a sewing mode that inputs a sensor signal 0 0/1 1=N-stitch Mode
in the edge sensor port and uses it as an edge sensor
47 Selection of pre-stitch function (When selected it will perform only 0 0/1 1=selection
the programmed stitches before the actual sewing work starts)
48 Pre-stitch number of stitches 3 stitches 0~255 1 stitch
49 Pre-stitch speed 2000spm 20~2000 10spm
50 Selection of start B/T operating conditions 0 : B/T stop function selected
( 0 : if pedal is released during back tack, it will stop) 1 1 : B/T work completion
( 1 : if pedal is released during back tack, the work will still be completed) 2 : B/T exact stitch performance
( 2 : it will perform the exact amount of back tack stitches)
51 Selection of end back tack performance condition 0 0/1 1= exact stitch performance
(It will perform the exact amount of stitches for end back tack )
52 Back tack initial first stitch speed during back tack exact performance 200spm 20~1000 10spm
Caution
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the
user must be well-trained before using it.
