(2) Group B Parameter : All types of output, Full-on Time/PWM Duty, checking input/output operations, sewing
machine models and thread trimming sequence programming.
※ These are functions not used by general users and must be regulated by an A/S technician.
No. Function StepRange
Initial value
※ Items No. 30~33 : These are the items that make the number of stitches match when back tack number of stitches do not match.
※ Solenoid Duty Ratio : The power that holds and maintains the solenoid.
Solenoid initial full on time : The time it takes to pull the solenoid to the maximum in the outset.
1 Back Tack Solenoid Initial Full On Time 1020ms 4~1020 4ms
2 Presser Foot-Lift Solenoid Initial Full On Time 200ms 4~1020 4ms
3 T/T Solenoid Initial Full On Time 100ms 4~1020 4ms
4 Wiper Solenoid Initial Full On Time 100ms 4~1020 4ms
5 Tension Release Solenoid Initial Full On Time 100ms 4~1020 4ms
6 Left Solenoid Initial Full On Time (For Twin Needle) 100ms 4~1020 4ms
7 Right Solenoid Initial Full On Time (For Twin Needle) 100ms 4~1020 4ms
8 Auxiliary Solenoid Initial Full On Time 100ms 4~1020 4ms
9 Left LED Initial Full On Time (For Twin Needle) 100ms 4~1020 4ms
10 Right LED Initial Full On Time (For Twin Needle) 100ms 4~1020 4ms
11 Needle plate up-stop signal Initial Full On Time 100ms 4~1020 4ms
12 Needle plate down-stop signal Initial Full On Time 100ms 4~1020 4ms
13 Signal notifying motor running Full On Time 100ms 4~1020 4ms
14 Signal notifying target speed achieved Full On Time 100ms 4~1020 4ms
15 Back Tack Solenoid Duty Ratio 50% 0~100 10%
16 Presser Foot-Lift Solenoid Duty Ratio 20% 0~100 10
17 Thread Trimming Solenoid Duty Ratio 100 0~100 10
18 Wiper Solenoid Duty Ratio 100 0~100 10
19 Tension Release Solenoid Duty Ratio 100 0~100 10
20 Left Solenoid Duty Ratio (For Twin Needle) 50 0~100 10
21 Right Solenoid Duty Ratio (For Twin Needle) 50 0~100 10
22 Aux Solenoid Duty Ratio 100 0~100 10
23 Left LED Duty Ratio (For Twin Needle) 100 0~100 10
24 Right LED Duty Ratio (For Twin Needle) 100 0~100 10
25 Signal for up stopping needle Duty Ratio 100 0~100 10
26 Signal for low stopping needle Duty Ratio 100 0~100 10
27 Signal notifying motor running Duty Ratio 100 0~100 10
28 Signal notifying target speed reached Duty Ratio 100 0~100 10
29 NOT USED
30 Start Back Tack A number of stitches correction value 00.30 6~6 0.05 Stitch
31 Start Back Tack B number of stitches correction value 00.30 6~6 0.05 Stitch
32 End Back Tack C stitch correction value 00.40 6~6 0.05 Stitch
33 End Back Tack D stitch correction value 00.40 6~6 0.05 Stitch
34
Selection for maintaining reverse solenoid movement when thread trimming (C Only B/T)
0 0/1 1=reverse direction maintained
35 Programming count condition 0 0/1 0=counter used
(program whether or not automatic counter will be operated)
1=automatic counter after thread trimming
36
When automatically counting, select Up/Down count after thread
1 0/1
1=Up COUNT
trimming (thread trimming function must be enabled) 0=DOWN COUNT
0=buzzer rings, sewing is allowed
37 When count in completeded, the next operation is programmed 0 0/1/2
1=buzzer rings, sewing is not allowed
(If you press the Prog Key, set up is cancelled)
2=No buzzer ring, sewing is allowed
38 When count is completed, select the counter auto clear/preset 0 0/1
1=AUTO
CLEAR/PRESET
39 NOT USED
Caution
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the
user must be well-trained before using it.
