79
Category
3rd2nd1st
Data Field
Cmd FieldExplanation
Motor
Control
Position
/Speed
Check
On Hold Motor-Holding Start C0H
Off Hold Motor-Holding Stop C1H
Set Dir CW Set CW direction) C2H
Set Dir CCW Set CCW direction) C3H
Set Speed Make Motor Run with given Speed C4H 0~5000[spm]
(20spm)
Set SpdByPed Make Motor Run with Speed given by pedal C5H
Up Stop Make Stop in Needle Up (stop) C6H
DN Stop Make Stop in Needle Down (stop) C7H
Up Stop InSpd Make Up Stop with given Speed (stop) C8H 0~500[spm]
(2spm)
Dn Stop InSpd Make Dn Stop with given Speed (stop) C9H 0~500[spm]
(2spm)
Dacc Up Edge Decel. in Speed at Up Edge (not stop) CAH 0~500[spm]
(2spm)
Dacc Dn Edge Decel. in Speed at Dn Edge (not stop) CBH 0~500[spm]
(2spm)
Move Up Edge Move to Up Edge with given Speed (not stop) CCH 0~500[spm]
(2spm)
Move DnEdge Move to Dn Edge with given Speed (not stop) CDH 0~500[spm]
(2spm)
Pos Stop Up Up Stop after sewing given stitch with given Speed CEH 0~5000[spm] 0~255[stitch]
(20spm)
Pos Stop Dn Dn Stop after sewing given stitch with given Speed CFH 0~5000[spm] 0~255[stitch]
(20spm)
Pos Dacc Up Dacc Dn Edge after sewing given stitch with given Speed D0H 0~5000[spm] 0~500[spm] 0~255[stitch]
(20spm) (2spm)
Pos Dacc Dn Dacc Up Edge after sewing given stitch with given Speed D1H 0~5000[spm] 0~500[spm] 0~255[stitch]
(20spm) (2spm)
L Move Stop Move given distance with given Speed D2H 0~ 500[spm] 0~357[deg]
(2spm)
SpdInPos Make motor given Speed in given Position D3H 0~5000[spm] 0~357[deg]
(20spm)
Random Stop Stop randomly D4H
Wait Pos1 When position aleady passed, return E0H 0~357[deg]
Wait Pos2
When position aleady passed, wait next position
E1H 0~357[deg]
and then return
Wait Up Edge Wait until Up Edge detected. E2H
Wait Dn Edge Wait until Dn Edge detected E3H
Chk Pos Check the posiiton passed & branch to the address E4H 0~357[deg] 0~64 (address)
Chk Up Edge Check Up Edge detected & branch to the address E5H 0~64 (address)
Chk Dn Edge Check Dn Edge detected & branch to the address E6H 0~64 (address)
Clr Up Edge Clear Up Edge FG (mark UpEdge not detected) E7H
Clr Dn Edge Clear Dn Edge FG (mark DnEdge not detected) E8H
Wait Speed Wait until motor speed is target speed E9H
0~5000[spm]
(20spm)
Chk Speed
Check if motor speed is target speed &
EAH 0~357[deg] 0~64 (address)
branch to the address
