DR650SEK1 (’01-MODEL) 10-8
ITEM STANDARD LIMIT
Master cylinder bore
Front
12.700 – 12.743
(0.5000 – 0.5017)
———
Rear
12.700 – 12.743
(0.5000 – 0.5017)
———
Master cylinder piston diam.
Front
12.657 – 12.684
(0.4983 – 0.4994)
———
Rear
12.657 – 12.684
(0.4983 – 0.4994)
———
Brake caliper cylinder bore
Front
27.000 – 27.050
(1.0630 – 1.0650)
———
Rear
30.23 – 30.28
(1.1902 – 1.1921)
———
Brake caliper piston diam.
Front
26.90 – 26.95
(1.0591 – 1.0610)
———
Rear
30.16 – 30.18
(1.1874 – 1.1882)
———
Wheel rim runout
Axial ———
2.0
(0.08)
Radial ———
2.0
(0.08)
Wheel axle runout
Front ———
0.25
(0.010)
Rear ———
0.25
(0.010)
Tire rim size Front J21 × 1.85 ———
Rear J17 × MT2.50 ———
Tire size Front 90/90-21 54S ———
Rear 120/90-17 64S ———
Tire tread depth
Front ———
3.0
(0.12)
Rear ———
3.0
(0.12)
SUSPENSION Unit: mm (in)
ITEM STANDARD LIMIT NOTE
Front fork stroke 260
———
(10.2)
220
———
(8.7)
Low seat
Front fork spring free length
———
548
(21.6)
Front fork oil level 164
———
(6.5)
150
———
(5.9)
Low seat
