Suzuki DR650SE - Cylinder Head Cover

277 pages

To Next Page

To Previous Page

DR650SEK1 (’01-MODEL) 10-10

LIQUID GASKET

CYLINDER HEAD COVER

CYLINDER HEAD

NOTE:

SUZUKI BOND NO.1215

or NO.1207B has to be

applied to the cylinder head

cover and cylinder head.
