Suzuki RMX450Z Service Manual

1D-71 Engine Mechanical:
Special Tool
BA02J21408002
09900–06107 09900–06108
Snap ring remover (Open
type)
Snap ring remover (Close
type)
)(Page 1D-22) /
)(Page 1D-26)
)(Page 1D-63) /
)(Page 1D-65)
09900–20101 09900–20202
Vernier calipers (150 mm) Micrometer (25 – 50 mm)
)(Page 1D-43) /
)(Page 1D-45) /
)(Page 1D-51)
)(Page 1D-37)
09900–20204 09900–20205
Micrometer (75 – 100 mm) Micrometer (0 – 25 mm)
)(Page 1D-50) )(Page 1D-38) /
)(Page 1D-44) /
)(Page 1D-50) /
)(Page 1D-51)
09900–20530 09900–20602
Cylinder gauge set Dial gauge
)(Page 1D-48) )(Page 1D-38) /
)(Page 1D-51)
09900–20605 09900–20607
Dial calipers (10 – 34 mm) Dial gauge
)(Page 1D-61) )(Page 1D-43) /
)(Page 1D-43) /
)(Page 1D-44) /
)(Page 1D-61) /
)(Page 1D-62)
09900–20701 09900–20803
Dial gauge chuck Thickness gauge
)(Page 1D-43) /
)(Page 1D-43) /
)(Page 1D-44) /
)(Page 1D-61) /
)(Page 1D-62)
)(Page 1D-43) /
)(Page 1D-48) /
)(Page 1D-50) /
)(Page 1D-51) /
)(Page 1D-62)
09900–21304 09900–22301
V blocks Plastigage (0.025 – 0.076
mm)
)(Page 1D-43) /
)(Page 1D-43) /
)(Page 1D-61) /
)(Page 1D-62)
)(Page 1D-37)

Suzuki RMX450Z Specifications

General

Displacement	449cc
Compression Ratio	12.5:1
Fuel System	Fuel injection
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	96.0 mm x 62.1 mm
Front Brakes	Single disc
Rear Brakes	Single disc
Front Tire	80/100-21
Fuel Tank Capacity	6.2 L (1.6 US gal)
Overall Length	2185 mm (86.0 in)
Ground Clearance	325mm
Seat Height	955mm
Wheelbase	1, 480mm
