9. FINAL DRIVING MECHANISM
9-1
Mechanism Diagram - transmission cover
······························································ 9-1
Precautions in operation ···················· 9-2
Trouble Diagnosis······························· 9-2
Disassembly of Transmission············ 9-3
Inspection of Mission Mechanism···· 9-11
Bearing Replacement ························ 9-13
Re-assembly of Final Driving Mechanism
····························································· 9-16
Mechanism Diagram - transmission cover
Final shaft
Reverse shaft
Counter shaft
Drive shaft
Bearing (6204)
Home page
Contents
Gear oil fill bolt
3.5~4.5kgf-m
Shift fork
Oil seal
(25x40x7)
Oil seal
(
tc 25x40x9
)
Cover bolt
2.6~3.0kgf-m
Ta
pp
et Ad
j
Hole Ca
p
Ass
y
.
Bearing (6009)
Bearing (6305)
Bearing (6305)
Chan
g
e lever arm
Gear shift s
p
indle com
p
Drum shift
Mission shaft Mission box rear cover
Mission box
Bearing (6222 luu)
Mission box front cover
Left crank case
Eng. Oil drain bolt
3.5~4.5kgf-m
Thrust s
p
rin
g
Thrust s
p
rin
g
Bearing (6204)
Needle bearing
(HK2016)
Mission box rear cover
