10. ALTERNATOR/STARTING CLUTCH
10-1
Mechanism Diagram ··························· 10-1
Precautions in Operation···················· 10-2
Right Crankcase Cover Removal······· 10-3
A.C.G. Set Removal····························· 10-3
Right Cover Bearing···························· 10-3
Flywheel Removal································ 10-4
Starting Clutch ····································· 10-5
Flywheel Installation···························· 10-7
A.C.G. Set Installation··························10-8
Right Crankcase Cover Installation···· 10-8
Mechanism Diagram
5.0~6.0kgf-m
1.0~1.4kgf-m
0.8~1.2kgf-m
10
