4. FUEL SYSTEM
4-5
Carburetor Remove / Install(for
UA30A-6)
Removal
Drain out fuel in the float chamber.
Turn the fuel valve lever on off.
Remove 1 screw from throttle lever cap them
remove throttle lever cap.
Loosen throttle cable adjustment nut and remove
throttle cable
Disconnect the fuel hose and by-starter and drain
tube
Release 2 clamps strip of air cleaner and inner
pipe.
Remove the carburetor.
Installation
Install in reverse order of removal procedures.
To this chapter contents
fuel valve lever
Drain bolt
adjustment nut
1 screw
By-starter
Drain tube
Fuel hose
2 clamps
