2. MAINTENANCE INFORMATION
Precautions in Operation···················· 2-1
Periodical Maintenance Schedule······ 2-2
2-1
Fuel Lines············································· 2-3
Acceleration Operation ······················· 2-3
Air Cleaner············································ 2-3
Spark Plug············································ 2-3
Valve Clearance ··································· 2-4
Carburetor Idle Speed Adjustment····· 2-5
Ignition System···································· 2-6
Cylinder Compression Pressure ········ 2-6
Drive Belt·············································· 2-7
Drive Chain··········································· 2-7
Brake System (Disk Brake) ················· 2-10
Brake Light Switch/Starting Inhibitor
Switch ··················································· 2-11
Headlight Beam Distance···················· 2-12
Clutch Disc Wear ·································2-12
Cushion················································· 2-12
Steering Handle···································· 2-13
Wheel/Tire············································· 2-13
Nuts, Bolts Tightness·························· 2-13
Special Tools List ································2-14
2
Precautions in Operation
Specification
Fuel Tank Capacity 12000 c.c.
Capacity 1400 c.c.
Engine Oil
Change 1200 c.c.
Capacity 1300 c.c.
Transmission Gear oil
Change 1200 c.c.
Gear box oil 150 c.c.
Engine + radiator 850 c.c.
Capacity of coolant
Reservoir upper 420 c.c.
Clearance of throttle valve 1~3 mm
Type NGK CR8E
Spark plug
Gap 0.8 mm
BTDC 10º / 1700 rpm “F” Mark in idling speed
BTDC 27º / 4000 rpm Full timing advanced
Idling speed 1700±100 rpm
Cylinder compression pressure 12.0 ±2 kgf/cm²
Valve clearance IN:0.10 ± 0.02 mm EX:0.15 ± 0.02 mm
Front AT22x7-10
Tire dimension
Rear AT22x10-9
Tire pressure (cold) 3.8±2 psi
Battery 12V10Ah (MF battery) type: GTX12-BS
