6. CYLINDER HEAD/VALVE
6-1
Mechanism Diagram··························· 6-1
Precautions in Operation ··················· 6-2
Troubleshooting·································· 6-3
Cylinder Head Removal······················ 6-4
Cylinder Head Inspection··················· 6-7
Valve Stem Replacement··················· 6-10
Valve Seat Inspection and Service··· 6-11
Cylinder Head Reassembly··············· 6-13
Cylinder Head Installation················· 6-14
Valve Clearance Adjustment············· 6-16
Mechanism Diagram
6
0.7~1.1kgf-m
1.0~1.4kgf-m
1.0~1.4kgf-m
1.0~1.2kgf-m
3.6~4.0kgf-m
Home page
Contents
2.4~3.0kgf-m
1.0~1.4kgf-m
1.0~1.4kgf-m
1.0~1.4kgf-m
1.0~1.2kgf-m
