4. FUEL SYSTEM
4-18
Air Cleaner
Removal
FOR UA30A-6
Loosen the clamp strip of air cleaner and
carburetor, and then remove the vapor hose.
FOR UA30A1-6 and UA30A-A
Remove two nut from inner pipe and Loosen the
clamp strip of air cleaner and then remove the
vapor hose..
Loosen the clamp strip of air cleaner, and then
remove the air cleaner vapor hose.
Remove the air cleaner (4 bolts).
Installation
Install the tank in the reverse order of removal.
Cleaning air cleaner element
Remove the air cleaner cover (4 catch hooks).
To this chapter contents
Clamp
4 bolts
4 hooks
Clamp
Clamp
