RS-232 Host Interface 6 - 13

Baud Rate

Baud rate is the number of bits of data transmitted per second. Select the baud rate setting to match the baud rate setting of the

host device. Otherwise, data may not reach the host device or may reach it in distorted form.

Baud Rate 600

Baud Rate 1200
