Chapter 6RS-232 Host Interface
Introduction
This chapter provides information for setting up the scanner with an RS-232 host. Use the RS-232 interface to attach the scanner
to point-of-sale devices, host computers, or other devices with an available RS-232 port (e.g., com port). This scanner uses TTL
RS-232 levels to interface with all PC's without additional hardware.
Particularly noisy electrical environments may require a cable with an RS-232 transceiver. To obtain this
cable, contact the Global Customer Interaction Center.
If the particular host is not listed in Table 6-9, set the communication parameters to match the host device. See the
documentation for the host device.
Throughout the programming bar code menus, asterisks (
*) indicate default values.
Note
*Baud Rate 9600
Feature/Option
* Indicates Default
