Introduction
Synapse Smart cables interface to a variety of hosts. The appropriate Synapse Smart cable has built-in intelligence to detect the
host to which it is connected. An external power supply is required.
Figure 9-24 Synapse Connection Without Peripherals - Power Supplied Externally via Y-Cable
Host
Host Port
Synapse Smart Cable
To EAS (optional)
Power Port
