Symbol LS7708 - RS-232 Auxiliary Port Default Parameters

RS-232 Auxiliary Port 10 - 3
RS-232 Auxiliary Port Default Parameters
Table 10-15 lists the defaults for RS-232 auxiliary parameters. To change any option, scan the appropriate bar code(s) beginning
in RS-232 Auxiliary Port Parameters on page 10-4.
See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 10-15 RS-232 Auxiliary Port Default Parameters
Parameter Default Page Number
Baud Rate 9600 10-4
Parity None 10-7
Check Receive Errors Enable 10-9
Hardware Handshaking None 10-10
Software Handshaking None 10-13
Serial Response Time-out 2 Sec 10-16
RTS Line State Low RTS 10-18
Stop Bit Select 1 10-19
Data Bits 8-Bit 10-20
Note
