3 - 4 LS7708 Scanner Product Reference Guide
Technical Specifications
Table 3-1 Technical Specifications
Item Description
Physical Characteristics
Dimensions:
Without stand: Height
Width
Depth
6.3 in. (16 cm)
5.98 in. (15.2 cm)
3.73 in. (9.5 cm)
Weight Scanner only: 2.04 lbs. (925 g)
Power Source Power drawn from host terminal or external power supply; depends on host
type.
Voltage 5.5 VDC to 4.75 VDC measured at host terminal or external power supply
Current 390mA (nominal) / 500 mA maximum with no peripheral
Power (nominal) 2 watts with no peripheral
Mounting Options Integral mounting bracket
Color Cash Register White or Twilight Black
Performance Characteristics
Light Source 650nm visible laser diode
Print Contrast 25% minimum reflective difference
Scan Patterns Static: 24 scan lines
Raster: 120 scan lines
Scan Rate Static: 2,400 scans/sec.
Raster: 12,000 scans/sec.
Depth of Field 0-10 in./0-25.4 cm @ 13 mil (100% UPC/EAN)
Typical Working Range 5 mil: (38%) 0.5 to 2.5 in./ 1.27 to 6.4 cm
7.8 mil: (60%) 0 to 5 in./ 0 to 12.7 cm
10.4 mil: (80%) 0 to 7.5 in./ 0 to 19 cm
13 mil: (100%) 0 to 10.0 in./ 0 to 25.4 cm
Minimum Resolution 5 mil
Decode Capability UPC/EAN/JAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 128,
ISBT 128, Code 39, Code 39 Trioptic, Interleaved 2 of 5, Discrete 2 of 5, Code
93, Code 11, Codabar, RSS Variants
Interfaces Supported USB, RS-232, IBM® 468X/9X, Keyboard Wedge, and Synapse™ (allows
connectivity to virtually every POS host type), SPCI (for 123Scan)
User Environment
Operating Temperature 32° to 104°F (0° to 40°C)
Storage Temperature -40° to 140°F (-40° to 60°C)
Humidity 5% to 95% (non-condensing)
