6 - 2 LS7708 Scanner Product Reference Guide

Connecting an RS-232 Interface

There are several possible configurations for connecting to an RS-232 host. The scanner connects directly to the host computer.

Figure 6-19RS-232 Connection Without Peripherals - Power Supplied Externally

Host Port

Host Serial Port

To EAS (optional)
