1 - 6 LS7708 Scanner Product Reference Guide
Figure 1-3Scanner Connections
Different hosts require different cables. The connectors illustrated in each host chapter are examples
only. Connectors may be different from those illustrated, but the steps to connect the scanner are the
same.
Host
EAS Interlock
Power
Secondary Scanner (Synapse)RS-232 Aux
Scanner
Cable
Host
Interface
Cable
Power
Cable
RS-232 Aux Cable EAS Interlock Cable
Note
