TB7100 Installation and Operation Manual Preparation for Operation 101
© Tait Electronics Limited December 2005
The correct operation of the base station as an RF modem can be verified
by transferring text files between the two PCs.
7.6 Data Repeater
In data repeater mode the base station will transmit all valid received data.
Figure 7.7 RF modem test setup
Receiver
Transmitter
System Interface
Terminal
Application
Dummy Load
Antenna
Terminal
Application
TM8000 Mobile
Radio
PROG/MIC Tx/Rx CHANNEL POWER Tx BUSY F1 F3 F4F2 VOLUME
Figure 7.8 Data repeater
Receiver Transmitter
System Interface
RF In
RF Out
Rx Data
Tx Data
