108 Preparation for Operation TB7100 Installation and Operation Manual
© Tait Electronics Limited December 2005
Transmitter
Mandatory Settings
The mandatory settings for the transmitter are shown below, if these change
the transmitter will no longer operate.
7.8.4 User-defined Settings
The user-defined settings are specific to the customers application. These are
the only settings that need to be changed when configuring a base station
for operation. To set up a basic voice repeater or base station only the
channel information needs to be entered:
■ frequency
■ power level
■ bandwidth
■ squelch threshold
■ sub-audible signalling.
If the system is to be used for data then the data parameters also need to be
set correctly:
■ baud rate
■ flow control
■ error correction.
Form Tab Item Name Setting
Data General Output SDMs Automatically Disabled
Data Serial Communications Data_Port AUX
Data Serial Communications XON_Character 11
Data Serial Communications XOFF_Character 13
Basic Settings Sub Audible Signalling Invert Rx DCS Disabled
Channels Detailed RX_Frequency 000.000000
Channels Detailed RX Sig none
Channels Detailed Squelch hard
UI Preferences User Interface Confidence Tones Disabled
UI Preferences User Interface Silent Mode Disabled
UI Preferences Audible Indicators Enabled All Disabled
Startup Startup Power On Mode Power on
Startup Startup Reset On Error Enabled
PTT MIC PTT PTT Priority high
PTT MIC PTT Audio Source CH Mic
PTT External PTT 1 PTT Priority medium
PTT External PTT 1 Audio Source Audio Tap In
