1.1 Frequency Bands
The base station is available in the following frequency bands:
■ 66 to 88MHz (A4)
■ 136 to 174MHz (B1)
■ 216 to 266 MHz (D1)
■ 400 to 470MHz (H5)
■ 450 to 530MHz (H6)
■ 450 to 520MHz (H7)
The RF band of the base station is implemented by the frequency band of
the transmitter and receiver modules.
1.2 RF Output Power
The base station is available with 25W and 50W/40W RF output power.
The RF output power options are implemented by different transmitter and
receiver modules.
The 25W base station is available in the following frequency bands:
■ A4
■ B1
■ D1
■ H5
■ H6
The 50W/40W base station is available in the following frequency bands:
■ B1 (50W)
■ H5 (40W)
■ H7 (40W)
